The following are the product parameters of the two models XDC-450 and XDC-400:
| Product Model | Diameter | Thickness | Production speed | Distance of dripper |
| XDC-450 | Φ12-16-20-22-25mm | 0.12-0.6mm 0.2-1.0mm (optional) | 450m/min | 100,150,200,300,400,500-1500mm |
| XDC-400 | Φ12-16-20mm | 0.12-0.6mm 0.2-0.9mm (optional) | 400m/min | 100,150,200,300,400,500-1500mm |
●Drip head screening mechanism (2 units): It adopts centrifugal screening and identification method with a screening and identification speed of 4500 per minute. The unit can realize automatic identification and supply of drippers, automatically remove unqualified drippers, and ensure 100% pass rate.
●Extruder: High-speed dedicated single-screw extruder, PLC temperature system control, servo motor as drive to ensure high efficiency and high output of production.
●Water tank: The tank is made of stainless steel and consists of a vacuum water tank, a sizing sleeve, water filtration, sand prevention, and foreign body prevention devices. It is equipped with an anti-pipe rotation device, a pipe break alarm device, and an automatic detection and alarm device for pinhole leaks in the pipe wall.
●Fully automatic punching device: It is the most advanced mechanical technology in Europe, with a punching speed of 4000 times/min. It is controlled by a PLC system, and has an external automatic online imaging monitoring and punching, analysis and alarm device to ensure high-quality and stable production.
●Fully automatic winding and roll changing mechanism: controlled by the PLC intelligent system, it can automatically complete the steps of arranging, winding, cutting, changing rolls, counting meters, cutting, etc. of the dropper according to the required length requirements.
Focus on the exhibition
FAQ：
Q: What is the main selling point of your equipment?
A: Fast production speed. For example, the production speed of the XDC-450 drip irrigation pipe production line is 450m/min.
High degree of automation: The production line adopts PLC intelligent control system, which reduces manual intervention and ensures high-quality and efficient production of products.
Energy saving and environmental protection: It uses servo motor as drive, which is protection-free and saves
30% electricity.
Q: How do you control the quality of your products?
A: You can be absolutely assured of the quality. Our company has always been adhering to the concept of people-oriented, winning with innovation, and pursuing excellence with sincerity. Our products will undergo strict quality inspections, and we will provide shipment inspection videos.
Q: How is your after-sales service?
A: We provide on-site installation, commissioning and training, free spare parts and other services, and have video/online technical support.
Company information
Qingdao Xindacheng Plastic Machinery Co., Ltd. was established in 1998. It is mainly engaged in the research and development, production and sales of new plastic machinery, including various types of plastic extrusion machinery and complete sets of equipment such as drip irrigation pipes, strapping tapes, sheets, pipes, etc.
The company has passed the ISO9001 quality management system, intellectual property management system, and EU CE certification. It has 12 invention patents and 52 utility model patents.
It has won the honors of National Specialized "Little Giant", High-tech Enterprise, Shandong Province Gazelle Enterprise, Shandong Province's First (Set) of Technical Equipment, Qingdao Enterprise Technology Center, Qingdao Industrial Design Center, and China Institute of Water Resources and Hydropower Research 2010 Science and Technology Award.
So far, the company's products have spread all over the country and exported to the United States, Italy, Canada, South Korea, Japan, Russia, Ukraine, Czech Republic, Turkey, Mexico, Iran, Saudi Arabia, Egypt, Indonesia, Malaysia and other countries and regions, and are well received by users.
